Two kinds of alignment

The vignette("extent-alignment") vignette is about snapping an arbitrary extent to a grid. This vignette is about the relationship between two grids: when do their cells line up well enough that index arithmetic between them is exact?

Two grids share a lattice when their cell boundaries coincide. That requires two things:

1. Commensurate resolution - one resolution is an exact integer multiple of the other, in x and in y.
2. Matching origin - their origins differ by a whole number of the finer cells.

When both hold, every operation that maps a cell in one grid to a cell in the other (offset, resize, tile, reindex) is exact integer arithmetic: no floating-point negotiation, no half-cell shifts, no off-by-one ambiguity. When they do not hold, the functions here refuse to proceed rather than returning a plausible-looking but wrong answer. The design doc calls this the “alignment prison” - the refusal is the feature.

A single relative tolerance, sqrt(.Machine$double.eps), is used throughout for the whole-number tests, and is exposed as the tol argument.

A picture of the lattice

Here a 5x5 child grid sits on the same unit lattice as a 10x10 parent, shifted 2 cells right and 3 cells down. Every child cell boundary (blue) falls on a parent cell boundary (grey), which is exactly the condition is_aligned() tests and grid_offset() measures.

p_dim <- c(10L, 10L); p_ext <- c(0, 10, 0, 10)
c_dim <- c(5L, 5L);   c_ext <- c(2, 7, 2, 7)

op <- par(mar = c(1, 1, 1, 1))
plot(NA, xlim = c(0, 10), ylim = c(0, 11), asp = 1,
     axes = FALSE, xlab = "", ylab = "")

## parent lattice (origin at top-left: xmin, ymax)
abline(v = x_corner(p_dim, p_ext), h = y_corner(p_dim, p_ext), col = "grey85")

## child cells, drawn as segments clipped to the child extent
cx <- x_corner(c_dim, c_ext); cy <- y_corner(c_dim, c_ext)
rect(c_ext[1], c_ext[3], c_ext[2], c_ext[4], col = "#4C78A822", border = NA)
segments(cx, c_ext[3], cx, c_ext[4], col = "#4C78A8")
segments(c_ext[1], cy, c_ext[2], cy, col = "#4C78A8")

## the offset from the parent top-left to the child top-left
points(0, 10, pch = 19)
points(2, 7, pch = 19, col = "#4C78A8")
arrows(0, 10, 2, 10, length = 0.08)
arrows(2, 10, 2, 7, length = 0.08)
text(1, 10.4, "col = 2")
text(2.3, 8.5, "row = 3", adj = 0)

par(op)

grid_offset(p_dim, p_ext, c_dim, c_ext)
#> col row
#>   2   3

is_aligned()

is_aligned() tests the lattice relationship between two grids. It is symmetric (neither grid is privileged) and the check works whether the grids are the same resolution, or one is a coarser multiple of the other.

## same resolution, origins differ by a whole number of cells
is_aligned(c(10L, 10L), c(0, 10, 0, 10), c(5L, 5L), c(2, 7, 2, 7))
#> [1] TRUE

## origin shifted by half a cell: not aligned
is_aligned(c(10L, 10L), c(0, 10, 0, 10), c(5L, 5L), c(2.5, 7.5, 2, 7))
#> [1] FALSE

## a coarser grid on the same lattice (res 5 is a multiple of res 1)
is_aligned(c(10L, 10L), c(0, 10, 0, 10), c(2L, 2L), c(0, 10, 0, 10))
#> [1] TRUE

Alignment is not containment. A grid can be perfectly aligned to another and still lie entirely outside it:

## child sits far outside the parent, but on the same lattice
is_aligned(c(10L, 10L), c(0, 10, 0, 10), c(5L, 5L), c(20, 25, 20, 25))
#> [1] TRUE

Use intersect_extent() when you need to know about overlap.

grid_offset()

For two grids of equal resolution that share a lattice, grid_offset() returns the integer column and row offset from the parent’s top-left cell to the child’s top-left cell. The result is 0-based and may be negative or exceed the parent dimension (again, alignment is not containment).

## child starts 2 cells in and 3 cells down
grid_offset(c(10L, 10L), c(0, 10, 0, 10), c(5L, 5L), c(2, 7, 2, 7))
#> col row
#>   2   3

This is the number you need to reindex content (cell values, sparse runs, coverage fractions) from the parent’s coordinate system into the child’s. It requires identical resolution; if the resolutions differ, bring them together with snap_grid() or resize_grid() first.

## differing resolution is refused
try(grid_offset(c(10L, 10L), c(0, 10, 0, 10), c(5L, 5L), c(2, 7.5, 2, 7)))
#> Error in grid_offset(c(10L, 10L), c(0, 10, 0, 10), c(5L, 5L), c(2, 7.5,  :
#>   grid_offset requires identical resolution; use snap_grid() or resize_grid() first

snap_grid()

snap_grid() moves a grid’s extent so its cell boundaries fall on a parent grid’s boundaries, keeping its own resolution. Only the origin moves. This is distinct from align_extent() / vcrop(), which snap an extent and adopt the target grid’s resolution.

## a 2x2 grid at resolution 2, slightly off a unit lattice
snap_grid(c(2L, 2L), c(0.4, 4.4, 0.4, 4.4), c(10L, 10L), c(0, 10, 0, 10))
#> $dimension
#> [1] 2 2
#>
#> $extent
#> [1] 0 4 0 4

The snap is to the coarser of the two resolutions, anchored at the parent’s top-left origin, so the result is guaranteed to be aligned to the parent. The resolutions must be commensurate; otherwise there is no lattice to snap to and the function errors.

resize_grid()

resize_grid() changes resolution by a factor while keeping the extent fixed. The factor applies to the dimension, and must yield whole-number dimensions so the new lattice nests exactly within the old one (or vice versa).

## double the dimension (finer cells)
resize_grid(c(10L, 10L), c(0, 10, 0, 10), 2)
#> $dimension
#> [1] 20 20
#>
#> $extent
#> [1]  0 10  0 10

## halve the dimension (coarser cells)
resize_grid(c(10L, 10L), c(0, 10, 0, 10), 0.5)
#> $dimension
#> [1] 5 5
#>
#> $extent
#> [1]  0 10  0 10

Because the lattices nest exactly, resizing is reversible: resize by k then by 1/k returns the original grid:

g <- resize_grid(c(10L, 10L), c(0, 10, 0, 10), 2)
resize_grid(g$dimension, g$extent, 0.5)
#> $dimension
#> [1] 10 10
#>
#> $extent
#> [1]  0 10  0 10

A factor that would break the lattice (fractional dimensions) is refused:

try(resize_grid(c(10L, 10L), c(0, 10, 0, 10), 0.3))
#> $dimension
#> [1] 3 3
#>
#> $extent
#> [1]  0 10  0 10

You can pass separate x and y factors as c(xfactor, yfactor).

grid_tiles()

grid_tiles() partitions a grid into tiles of a given dimension. It is pure index arithmetic (how many tiles fit and what their extents are) with no data or I/O. Tiles are enumerated left to right, then top to bottom, matching cell order. Edge tiles at the right and bottom may be smaller than tile_dim.

tiles <- grid_tiles(c(10L, 7L), c(0, 10, 0, 7), c(4L, 4L))
length(tiles)
#> [1] 6

A 10x7 grid tiled at 4x4 gives a 3x2 arrangement (3 columns of tiles, 2 rows). Each tile carries its dimension, extent, and 0-based offset in the parent:

## the last tile in the first row (a right edge tile, only 2 cols wide)
tiles[[3]]
#> $dimension
#> [1] 2 4
#>
#> $extent
#> [1]  8 10  3  7
#>
#> $offset
#> col row
#>   8   0

## a bottom-row tile (only 3 rows tall)
tiles[[6]]
#> $dimension
#> [1] 2 3
#>
#> $extent
#> [1]  8 10  0  3
#>
#> $offset
#> col row
#>   8   4

Every tile is aligned to the parent, and the stored offset is exactly what grid_offset() recovers:

t6 <- tiles[[6]]
is_aligned(c(10L, 7L), c(0, 10, 0, 7), t6$dimension, t6$extent)
#> [1] TRUE
grid_offset(c(10L, 7L), c(0, 10, 0, 7), t6$dimension, t6$extent)
#> col row
#>   8   4

This makes grid_tiles() a natural front end for chunked reads or writes: compute the tile scheme up front, then use each tile’s offset and dimension to address the corresponding window of the source.

Summary

Function	Purpose
is_aligned()	Test whether two grids share a lattice (symmetric)
grid_offset()	Integer col/row offset between two equal-resolution grids
snap_grid()	Move a grid’s origin onto a parent lattice, keeping its resolution
resize_grid()	Change resolution by a whole-number factor, keeping the extent
grid_tiles()	Partition a grid into aligned tiles with offsets

These complement the extent-snapping functions in vignette("extent-alignment"): there you reconcile a loose extent with a grid; here you reason about grids that already live on a shared lattice.
