What is vaster?

The vaster package provides pure raster grid logic without requiring actual raster data. It separates the abstract mathematical operations of raster grids - dimension, extent, cell indexing, coordinate transformations - from data formats and file I/O.

This is useful when you need to:

  • Pre-compute grid operations before reading or writing data
  • Work with virtual grids and mosaics
  • Perform format-agnostic grid calculations
  • Build higher-level geospatial tools

The Virtual Grid Model

A raster grid in vaster is defined by just two components:

  1. Dimension: the number of columns and rows c(ncol, nrow)
  2. Extent: the bounding box c(xmin, xmax, ymin, ymax)
## a 10x5 grid covering [0, 100] x [0, 50]
dimension <- c(10, 5)
extent <- c(0, 100, 0, 50)

From these two pieces of information, all grid properties can be derived:

n_cell(dimension)
#> [1] 50
x_res(dimension, extent)
#> [1] 10
y_res(dimension, extent)
#> [1] 10

Every other property is read off these two vectors: the extent fixes the outer edges and the corners, while the dimension divides that range into cells.

dm <- c(4L, 3L); ex <- c(0, 100, 0, 75)
op <- par(mar = c(1, 1, 2, 1))
plot(NA, xlim = c(-20, 114), ylim = c(-12, 92), asp = 1, axes = FALSE, xlab = "", ylab = "")
abline(v = x_corner(dm, ex), h = y_corner(dm, ex), col = "grey80")
rect(ex[1], ex[3], ex[2], ex[4], lwd = 2)
text(ex[1], ex[4] + 7, "xmin, ymax", adj = 0, col = "#1C6E8C")
text(ex[2], ex[3] - 7, "xmax, ymin", adj = 1, col = "#1C6E8C")
arrows(0, 85, 100, 85, code = 3, length = 0.06); text(50, 91, "ncol = 4")
arrows(-9, 75, -9, 0, code = 3, length = 0.06); text(-16, 37.5, "nrow = 3", srt = 90)
## one cell carries the resolution
rect(0, 50, 25, 75, col = "#1C6E8C22", border = NA)
arrows(0, 46, 25, 46, code = 3, length = 0.05, col = "#1C6E8C")
text(12.5, 40, "x_res = 25", col = "#1C6E8C", cex = 0.9)
arrows(29, 50, 29, 75, code = 3, length = 0.05, col = "#1C6E8C")
text(33, 62.5, "y_res = 25", col = "#1C6E8C", cex = 0.9, adj = 0)

A 4x3 grid with its extent outlined and corners labelled xmin/ymax (top-left) and xmax/ymin (bottom-right); double arrows along the top and left mark ncol = 4 and nrow = 3, and one shaded cell is annotated with x_res and y_res.

par(op)

There is no data, no file format, no CRS - just the logical grid structure. This matches how GDAL and other tools internally represent grids.

Cell Numbering Convention

Cells are numbered from 1, starting at the top-left corner and proceeding row-wise (left-to-right, top-to-bottom). This matches the convention used by the raster and terra packages.

## cell numbers for a 4x3 grid
dimension <- c(4, 3)
extent <- c(0, 4, 0, 3)

## total cells
n_cell(dimension)
#> [1] 12

## cell 1 is top-left
xy_from_cell(dimension, extent, 1)
#>      [,1] [,2]
#> [1,]  0.5  2.5

## cell 4 is top-right
xy_from_cell(dimension, extent, 4)
#>      [,1] [,2]
#> [1,]  3.5  2.5

## cell 12 is bottom-right
xy_from_cell(dimension, extent, 12)
#>      [,1] [,2]
#> [1,]  3.5  0.5

The cell centre coordinates reflect this ordering:

## all cell centres
cells <- seq_len(n_cell(dimension))
xy_from_cell(dimension, extent, cells)
#>       [,1] [,2]
#>  [1,]  0.5  2.5
#>  [2,]  1.5  2.5
#>  [3,]  2.5  2.5
#>  [4,]  3.5  2.5
#>  [5,]  0.5  1.5
#>  [6,]  1.5  1.5
#>  [7,]  2.5  1.5
#>  [8,]  3.5  1.5
#>  [9,]  0.5  0.5
#> [10,]  1.5  0.5
#> [11,]  2.5  0.5
#> [12,]  3.5  0.5

The arrows trace the numbering: cell 1 is at the top-left origin, counting along each row before dropping to the next.

dm <- c(4L, 3L); ex <- c(0, 4, 0, 3)
cn <- seq_len(n_cell(dm)); ctr <- xy_from_cell(dm, ex, cn)
op <- par(mar = c(1, 1, 1, 1))
plot(NA, xlim = c(0, 4), ylim = c(0, 3), asp = 1, axes = FALSE, xlab = "", ylab = "")
abline(v = x_corner(dm, ex), h = y_corner(dm, ex), col = "grey80")
rect(ex[1], ex[3], ex[2], ex[4])
for (r in 1:3) {
  y <- unique(ctr[row_from_cell(dm, cn) == r, 2])
  arrows(0.15, y, 3.85, y, length = 0.06, col = "#1C6E8C44")
}
text(ctr[, 1], ctr[, 2], cn, font = 2)
points(0, 3, pch = 19, col = "#1C6E8C")

A 4x3 grid with cells numbered 1 to 12 at their centres, left to right then top to bottom; a dot marks the top-left origin at cell 1 and faint arrows along each row show the row-wise counting direction.

par(op)

Resolution and Origin

Resolution is the cell size in x and y directions:

dimension <- c(10, 5)
extent <- c(0, 100, 0, 50)

x_res(dimension, extent)
#> [1] 10
y_res(dimension, extent)
#> [1] 10

The origin is the point where cell boundaries align. By default, vaster uses the bottom-left corner of the extent:

origin(dimension, extent)
#> [1] 0 0

Understanding the origin is important for aligning multiple grids - covered in detail in vignette("extent-alignment").

Extent Properties

Extract individual extent components, dimension is obviously irrelevant for extent components but is included for consistency with other functions.

extent <- c(-180, 180, -90, 90)

x_min(c(1, 1), extent)
#> [1] -180
x_max(c(1, 1), extent)
#> [1] 180
y_min(c(1, 1), extent)
#> [1] -90
y_max(c(1, 1), extent)
#> [1] 90

xlim(c(1, 1), extent)
#> [1] -180  180
ylim(c(1, 1), extent)
#> [1] -90  90

Coordinate Arrays

Generate coordinate vectors for all columns or rows:

dimension <- c(4, 3)
extent <- c(0, 4, 0, 3)

## x coordinates of cell centres (one per column)
x_centre(dimension, extent)
#> [1] 0.5 1.5 2.5 3.5

## y coordinates of cell centres (one per row)
y_centre(dimension, extent)
#> [1] 0.5 1.5 2.5

## x coordinates of cell corners/edges (ncol + 1 values)
x_corner(dimension, extent)
#> [1] 0 1 2 3 4

## y coordinates of cell corners/edges (nrow + 1 values)
y_corner(dimension, extent)
#> [1] 0 1 2 3

For a full matrix of all cell centre coordinates:

xy(dimension, extent)
#>         x   y
#>  [1,] 0.5 2.5
#>  [2,] 1.5 2.5
#>  [3,] 2.5 2.5
#>  [4,] 3.5 2.5
#>  [5,] 0.5 1.5
#>  [6,] 1.5 1.5
#>  [7,] 2.5 1.5
#>  [8,] 3.5 1.5
#>  [9,] 0.5 0.5
#> [10,] 1.5 0.5
#> [11,] 2.5 0.5
#> [12,] 3.5 0.5

Comparison with raster/terra

The vaster approach differs from raster and terra in that there is no object to create or manage. Grid operations are pure functions:

## terra approach
library(terra)
r <- rast(ncol = 10, nrow = 5, xmin = 0, xmax = 100, ymin = 0, ymax = 50)
res(r)
ncell(r)
xyFromCell(r, 1)

## vaster approach
dimension <- c(10, 5)
extent <- c(0, 100, 0, 50)
c(x_res(dimension, extent), y_res(dimension, extent))
n_cell(dimension)
xy_from_cell(dimension, extent, 1)

This functional approach is useful when you need to perform many grid calculations without the overhead of object creation, or when working in contexts where raster packages aren’t available.
